Introduction & Prerequisites

In this guide, we will go through steps to integrate github actions into our production server. In our previous How to Deploy Django to Production blog, we discssed about how can we deploy our django website to production. Everytime we update our code and push it to github, we need those changes to reflect in our production server too. But we need to manually perform those repetitive tasks which is overwhelming. To solve this, we can use github actions which will help us implment continuous delivery on ur project.

We are assuming you already have followed our How to Deploy Django to Production tutorial or you already have a django project deployed on Ubuntu 22.4 server. We assume you have hosted your project on github and aready configured server access to your github repository using our previous tutorial if your project is private. To understand this blog in short time, you will require knowledge on topis like:

What is github and git
What is CI/CD (we will discuss here)
Basic knowlegde of bash scipting is a plus

How this works ?

Github provides us a service named github actions that allows us to automate tasks and workflows directly within your GitHub repository. It works on these steps:

We create .yaml files inside .github/workflows directory inside our project. These YAML files contain the configuration for our workflows, including the events we want to trigger when deploying and the actions to be performed.
We trigger the workflow by simply pushing our project repository to github. We can customize it too.
When the trigger occurs, github automatically starts workflow defined in .yaml file. We will create a pre-defined script that will perform repetative tasks for us.
The scripts will be used to execut commands inside our production server and once it is done, our server will host a fresh website.
We can view the status of worflow and actions inside actions section of our github repository.
Everytime we push our new changes to github or trigger the worflow, same process happens again and again.

Project Configuration

Let's start configuring our project for CI/CD. Follow these steps accordingly to ensure easy and smooth process:

Go to your project root and open project in VS Code or any editor you prefer.
Create a folder named .scripts inside project root folder.
Inside .scripts folder, create a file named deploy.sh file.(You can name <anything>.sh but I use it for convenience)

Paste this code inside deploy.sh and save file:

#!/bin/bash
set -e

echo "Deployment started ..."

# Pull the latest version of the app
echo "Copying New changes...."
git pull origin master
echo "New changes copied to server !"

# Activate Virtual Env
source <zvenv>/bin/activate             # activate your virtual environment. change zvenv with your venv name
echo "Virtual env '<zvenv>' Activated !"

echo "Clearing Cache..."
python manage.py clean_pyc
python manage.py clear_cache

echo "Installing Dependencies..."
pip install -r requirements.txt --no-input

echo "Serving Static Files..."
python manage.py collectstatic --noinput

echo "Running Database migration..."
python manage.py makemigrations
python manage.py migrate

# Deactivate Virtual Env
deactivate
echo "Virtual env '<zvenv>' Deactivated !"

echo "Reloading App..."
ps aux |grep gunicorn |grep <project__name> | awk '{ print $2 }' |xargs kill -HUP                     # insert project name here.

echo "Deployment Finished !"

Now we need to go to .scripts folder and set file permissions to git. It helps to prevent permissions issue later in server.
```
$ cd .scripts
$ sudo git update-index --add --chmod=+x deploy.sh
```

Now we have to create directory named .github inside your root project folder. And then create folder named workflows inside .github. Eg:

zvenv
myproject
     - .scripts/deploy.sh
     - .github/workflows
     -  manage.py
     -  requirements.txt
     - myproject
        - settings.py

Inside .github/workflows, create a file named deploy.yml . Again strict file name is not necessary but recommended.

Paste this code inside deploy.yml file and save file:

name: Deploy

# Trigger the workflow on push and
# pull request events on the master branch
on:
  push:
    branches: ["master"]
  pull_request:
    branches: ["master"]

# Authenticate to the the server via ssh
# and run our deployment script
jobs:
  deploy:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3
      - name: Deploy to Server
        uses: appleboy/ssh-action@master
        with:
          host: ${{ secrets.HOST }}
          username: ${{ secrets.USERNAME }}
          port: ${{ secrets.PORT }}
          key: ${{ secrets.SSHKEY }}
          script: "cd /home/<username>/web/<projectname> && ./.scripts/deploy.sh"             # change directory accordingly.

Note: If you have your project inside /home/username/demowebsite then use accordingly. I have assumed that my project is inside /home/user/web/demowebsite. I use this because I keep zvenv and project folder inside web like:
```
home
   - username
         - web
            - zvenv      # my virtual env name
            - demowebsite    # my root project folder
               - manage.py
```

Server and Github Setup

Now that we have done essential configuration in our project folder. We will need to do some configurations in Ubuntu server and github too.

Github Setup

Go to your Github project repository and click on Settings.
Click on Secrets and Variables from the Sidebar then choose Actions
On Secret Tab, Click on New Repository Secret

Add Four Secrets HOST, PORT, USERNAME and SSHKEY as below:

Name: HOST
Secret: Your_Server_IP

Name: PORT
Secret: Your_Server_PORT       #mostly 22

Name: USERNAME
Secret: Your_Server_User_Name   #use whoami command to get username

Let's create a ssh key. You can use old but I am creating new for reference. Use:

ssh-keygen -f /home/<username>/.ssh/gitaction_ed2551920 -t ed25519 -C "gitactionautodep"        #name can be anything

Let's copy public SSH keys we created just now and paste it to authorized_keys files. Typically authorized_keys file is inside .ssh/authroized_keys directory :

$ cat ~/.ssh/gitaction_ed25520.pub        # again name can be anything you choose instead of gitaction_ed25520
$ cd .ssh
$ sudo nano authorized_keys                 # enter password if it demands password for sudo command

Now save the file using CTRL + X, then Y, then enter.

Now we need public key to save as SSHKEY in our github actions secrets. Just copy and paste using:

#copy public key:
$ sudo cat ~/.ssh/gitaction_ed25520

#go to your github settings where we left and paste:
Name: SSHKEY                        # name must be SSHKEY or same aswe setup in deploy.yml file
Secret: Private_SSH_KEY_Generated_On_Server

Now just go to VS Code, make a simple change and git push your repository for once. The workflow should trigger and become automatic

Conclusion

In this tutorial we have learned how to automate django deployment and use github actions to achieve continuous delivery of our fresh django website. We have discussed on basic topics that we need to know before achieveing continuous deployment. From next git push, your code will be automatically update on server which will save tons of time.
